Yisen Commercial EV FastMLH Charger DC Ocpp Solar Power Charging Station
Product name : Yisen Commercial EV FastMLH Charger DC Ocpp Solar Power Charging Station
Model No. : YS2303106
Price : 3850$-4055$
Products Category: > EVs Charging pile
Yisen Commercial EV Fast Charger DC Ocpp Solar Power Charging Station
| Production Parameters | ||
| Model | 40KW | |
| AC Input | Input voltage | 260-475V |
| AC Input Connection | 3P + N +PE, Wye connection | |
| Max. Input Current | 64A | |
| Frequency | 50 /60 Hz | |
| Power Factor | >0.99@full load | |
| Efficiency | 95% | |
| DC Output | Output Voltage Range | 200-750Vdc |
| Max. Output Power | 40KW | |
| Max. Output Current | 133A | |
| User Interface | TFT-LCD Touch Panel | Yes(swiping card without TFT-LCD Touch Panel) |
| Push Buttons | Yes | |
| Interface | Yes | |
| Packing | Dimension | W:721×475× 232 U:1500×520× 250 |
| Weight | 64KG | |
| Environmental | Operating Temperature | -20~50ºC,25ºC(TYPE) |
| Humidity | 5%-90% RH, non-condens,ng | |
| Altitude | 2000m | |
| IP Level | IP54 | |
| Mechanical | Cable Length | 5M (CHAdeMO) , 5M (CCS), 5M(GB/T) Customized acceptable |
| Regulation | EN61851-1 | |
| Regulation | Certification | CE , ROHS |
| Charging protocol | CHAdeMO 2.0 / DIN 70121/ISD1S118/IEC618Sl-23,IEC618Sl-24 | |
-4595243.jpg "Yisen-Commercial-EV-Fast-Charger-DC-Ocpp-Solar-Power-Charging-Station.webp (1).jpg")
-7813551.jpg "Yisen-Commercial-EV-Fast-Charger-DC-Ocpp-Solar-Power-Charging-Station.webp (2).jpg")
-9496107.jpg "Yisen-Commercial-EV-Fast-Charger-DC-Ocpp-Solar-Power-Charging-Station.webp (3).jpg")
-2363233.jpg "Yisen-Commercial-EV-Fast-Charger-DC-Ocpp-Solar-Power-Charging-Station.webp (5).jpg")
-7410902.jpg "Yisen-Commercial-EV-Fast-Charger-DC-Ocpp-Solar-Power-Charging-Station.webp (4).jpg")
