11KW Fast Electric Car Charger IP55 Wall/Post Home Car Charging Station 5m Long Cable
Product name : 11KW Fast Electric Car Charger IP55 Wall/Post Home Car Charging Station 5m Long Cable
Model No. : YS23071306
Price : 295$/set-350$/set
Products Category: > EVs Charging pile
11KW Fast Electric Car Charger IP55 Wall/Post Home Car Charging Station 5m Long Cable
| power level | 11kw |
| power supply | 3P+N+PE |
| Input voltage | 400Vac |
| input frequency | 50Hz |
| The output voltage | 400Vac |
| Output current | 16A |
| charging port | (National Standard/European Standard) Charging Gun |
| gun line length | 5m |
| start method | Plug and play, scan code, swipe card |
| Communication Interface | Wifi/RS485 |
| letter of agreement | Support multi-platform protocol |
| LED indicator | Tricolor |
| Leakage Protection | DC6mA |
| degree of protection | IP55 |
| Executive standard | EN/IEC62196-2 EN/IEC61851-1 ENMEC61851-21-2 |
| protection design | Undervoltage protection, overvoltage protection, short circuit protection, anti-shock protection, overload protection, over temperature protection, low temperature protection, full application protection, grounding protection |
| cooling method | natural cooling |
| Operating temperature | -30℃-55℃ |
| Working humidity | 5%-95% non-condensing |
| working altitude | <2000m |
| installation method | Wall-mounted, column-mounted (optional) |
| Alignment | bottom line, bottom line |
| Product size (wide, high, deep) | 205*350*13mm |
The design follows the principle of environmental protection and low energy consumption, saving energy and electricity; automotive-grade industrial design aesthetics, exquisite and compact appearance; APP-key charging, supports scheduled charging, saving time and more economical; lP55 protection level, anti-UV design, achieving high protection and long life .
